Product Description
Welcome to your bathroom. IMO unites two prevalent formal expressions, combining a round body with a rightangled lever and spout. This hybrid-shape design lends the series a universality, which appears modern, clear-cut and high-quality. IMO is the fitting for all those who want to design their bathroom themselves.
Product Number | 25 863 671-27 |
EAN Number | 4099477207674 |
Application area | Bath |
Series correlation | IMO |
Brand | Dornbracht |
Product Detail
- 279mm projection
- Spout: cascade
- Hand shower: COMPACT RAIN, max. flow rate 6.8 l/min (at 3 bar)
- Bar-type hand shower with anti-scale system
- Wall bracket
- Automatic bath/shower diverter
- Total height 943 - 1013 mm
- Stand pipe height 548 - 618 mm
- Height up to aerator 891 – 961 mm
- Metal shower hose 1250mm with integrated anti-twist protection
- Max. flow for complete hand shower set 6.8 l/min
- Slide-on rosettes Ø 135 mm
