Shower Pipe With Shower Thermostat With Hand Shower Set Flowreduce
Shower pipe with shower thermostat with hand shower set FlowReduce - 34 468 979-33 0070

Shower pipe with shower thermostat with hand shower set FlowReduce

Product Number34 468 979-33 0070
EAN Number4099477441535
Finishes
Chrome
Chrome
Dark Chrome
Dark Chrome
Light Gold
Light Gold
Brushed Light Gold
Brushed Light Gold
Matte Black
Matte Black
Brushed Bronze
Brushed Bronze
Brushed Chrome
Brushed Chrome
Brushed Dark Platinum
Brushed Dark Platinum

Matte Black

Product Description

Product Number34 468 979-33 0070
EAN Number4099477441535
Flow rate Max.6.8 l/min
BrandDornbracht

Individual colours:  For many series, we put the entire range of RAL colours into effect as painted surfaces - from a minimum quantity of one.

Expanding the variety of finishes: With electroplating technology, PVD, powder-coating or wet painting, the possibilities are almost limitless

Product Detail

  • Rain shower:
  • Rain shower Ø 300 mm
  • Material rain shower: plastic
  • PURE RAIN, max. flow rate 6.6 l/min (at 3 bar)
  • Function from: l/min
  • Rain shower with anti-scale system
  • Hand shower:
  • Spray head Ø 120mm
  • COMPACT RAIN, max. flow rate 6.8 l/min (at 3 bar)
  • Hand shower with anti-scale system
  • Inherently safe from back flow
  • Control element:
  • Rotary diverter with volume control and shut-off function
  • Plastic hose, 1750 mm, with integrated anti-twist protection
  • Slide bar
  • Technical dimensions:
  • Shower with fixed riser projection 454mm
  • Height of fittings up to rain shower (bottom edge) 980mm
  • Height of fittings up to top edge of elbow 1146mm
  • Slide-on rosettes Ø 70 mm
  • Gauge 150 mm - 13 mm
  • Pipe diameter 20 mm
  • 1/2" connection
  • Notes:
  • This product can help a building meet the requirements of Green Building Rating Systems, e.g. LEED®, BREEAM®, DGNB
